Remote Control Electric Overhead Travelling Crane With Hoist A3

Name: Remote Control Electric Overhead Travelling Crane With Hoist A3
Brand: KuangYuan
Price: 1 USD

China Remote Control Electric Overhead Travelling Crane With Hoist A3 wholesale

Brand Name : KuangYuan

Model Number : LDA

Certification : CE ISO

Place of Origin : Henan, China

MOQ : 1 SET

Price : Negotiation

Payment Terms : T/T, L/C, Western Union

Supply Ability : 30000 sets per year

Delivery Time : 35days

Packaging Details : high quality plywood crate and plastic woven cloth

Application : plants warehouse, material stocks

Span : 7.5~31.5m

work duty : A3

Feature : cheap price

Warranty : 12 months

Condition : New

Color : Red or customized

Lifting capacity : 16~20 ton

Contact Now

Remote Control Electric Overhead Travelling Crane With Hoist A3

Product Introduction of Remote Control Electric Overhead Travelling Crane With Hoist A3:

Remote Control Electric Overhead Travelling Crane With Hoist A3 supported on each side by an end truck. The electric hoist (electric wire rope hoist & electric chain hoist) are underhung—meaning they run on the bottom flange of the single girder. 10 Ton Single Girder Overhead Crane is typically less expensive due to:

1. Reduce transportation costs
2. Faster installation
3. Simpler hoist and trolley design
4. Lighter runway beam

Safety Features of Remote Control Electric Overhead Travelling Crane With Hoist A3:

Weight overload protection device, top quality durable polyurethane buffer, crane travelling limit switch, low voltage protection function, emergency stop system, current overload protection function.

The basic parameter of our Remote Control Electric Overhead Travelling Crane With Hoist A3:

Crane Travelling Mechanism	Working speed(m/min)		(Ground control)20	(Ground control)30	(Cabin control)
	Speed ratio		58.78	39.38	26.36
	Motor	type	YSE80L-4	YSE90L-4	ZDR100-4
		power(kw)	2*0.8	2*1.5	2*1.5
		rotational speed(m/min)	1380 5
Lifting Machanism(electric hoist)&electric hoist travelling mechanism	Model of electric hoist		MD1 model		CD1 model
	Lifting speed(m/min)		8/0.8(7/0.7)		8(7)
	Hoisting height(m)		6/9/12/18/24/30
	Traveling speed(m/min)		20
	Motor		Cone squirre-cage model
Working class			A3
Electric current			3-phrase 50HZ 380V
Wheel diameter			Φ270
Width of trail			37-70mm

Packaging &Shipping Details:

1. The beams are packed in woven bags or bubble paper;
2. The electrical parts are packed in plywood boxes;
3. The walking rails inside the container will be exposed
4. The crane is transported in containers or in bulk.

Remote Control Electric Overhead Travelling Crane With Hoist A3

Delivery cases:

1.Pakistan: 50+ Sets of Overhead Cranes &gantry crane to Pakistan

2.Mongolia: 7 Sets of Gantry Crane &overhead cranes To Mongolia

3.Russia: RMG Crane(36T/25M, Working At-40℃) To Krasnodar In Russia
4.China: Many Sets of 4-Beams Casting Cranes (YZS 250/50t) To BaoSteel In China

FAQ:

1. How can I get a precise crane offer?

A. To providing you a precise crane offer efficiently, please kindly provide details as following:

a). Lifting capacity, material weight(unit as tonnage)

b). Lifting height; (unit as meter)

c). Crane span, the width of inquired crane(unit as meter)

d). Crane traveling length; when rail track/runway beam needed, traveling length shall be provided

e) Working power; power source at site(unit as voltage, phase and Hz)

2. Can I get your crane products with customized personalized service?

A. Yes, Henan Mine Group promises to provide our customers with customized and personalized products at any time. Just freely tell us your special requirements for the product, and our engineering team will work on this.

3. What should I do if l'm not able to install the crane after buying?

A. Contact us for free. Our engineering team can provide overseas services for crane installation, inspection and commissioning.

4. How long I can receive my crane products after my order placed?

A. Our production will be started once the payment confirmed. We will deliver the equipment in 35 days. The arrival time varies according to your location, as for the specific time welcome to communicate with us directly.
